Hayward – W3SP2607X10 Super Pump 1 HP Single Speed Pool Pump, 115/230V

Hayward W3SP2607X10 Super Pump 1HP Single Speed Pool Pump, 115/230V set the industry standard for excellence and value while also meeting DOE efficiency regulations.

The Hayward W3SP2607X10 Super Pump 1 HP Single Speed Pool Pump features a heavy-duty, high-performance motor and airflow ventilation that provides quieter, cooler, more efficient operation for virtually any in-ground pool or spa. This 1HP single speed pump is a step down from Hayward Super Pump 1.5HP Single Speed Pump models SP2610X15 and W3SP2610X15. The Hayward Super Pump boasts many convenient features such as a large leaf strainer pump basket for capturing debris and a see-through pump lid to make cleaning quick and effortless. The durable weatherproof mounting base provides stability during operation, making it quieter than other competitor’s pumps.

Hayward Super Pump Power

The Hayward Super Pump 1 HP Single Speed Pool Pump comes standard with a corrosion-proof impeller to produce more flow through while preventing fouling and clogging. The Hayward pump’s Super-Size housing and diffuser guarantee you rapid priming at every start up. The heat-resistant industrial ceramic seal and thermoplastic body of the pump establish a long-wearing and drip proof unit that is durable and built to last. Hayward Super Pump medium-head pumps set the industry standard for excellence and value.

Hayward Super Pump Convenience

The Hayward Super Pump was manufactured with a service-ease design giving the owner or service technician simple access to all internal parts. With quick and easy 4-bolt access, the entire pump assembly can be removed exposing the internal components without interrupting the pipe or mounting connections. On top of the pump strainer housing are swing-away hand knobs, providing swift removal and easy access to the strainer basket.

With these and other advanced features, it’s easy to see why the Hayward 1 HP Super Pump is the industry’s most trusted workhorse and the best option for your inground pool or spa.

Common Questions:

What type of pump is the Hayward Super Pump?

• The Hayward Super Pump is a medium head pool pump designed to work with a single body of water for in ground pools or spas.

What size ports does the Hayward W3SP2607X10 Super Pump have?

• The Hayward 1HP Super Pump has 2-inch intake and discharge ports on the pump housing.

What are the specs of the Hayward W3SP2607X10 Super Pump?

• The Hayward Super Pump is a 1HP single speed pump capable of 115/230V and has a Weighted Energy Factor (WEF) of 3.4.

Please Note: Hayward Super Pump W3SP2607X10 is for installation on in ground pools and spas ONLY.

Product Type:	Pool Pump
Horsepower:	1 HP
Voltage:	115V / 230V
Installation Type:	Residential
Pump Speed:	Single
Rating Type:	Up-Rated
Service Factor:	1.1
Pool Type:	In Ground
Compatible Motors:	UST1102
Compatible Motors:	UCT1102
Compatible Motors:	RB053
Compatible Motors:	USTG1102A
Manufacturer:	Hayward
Same Series As:	Hayward Super Pump SP2610X15 & W3SP2610X15
Product Dimensions:	11″ Width x 29.8″ Length x 12″ Height
Product Weight:	34.155 lbs.
Warranty:	3-Year
